Nano
Smart body, desktop-class rigid body tracking system that provides 6DOF information for tracking targets and ensures tracking accuracy. Often suitable for small space accurate positioning, smart blackboard, desktop level positioning
Very large FOV
Nano can effectively track a distance of 3 meters while FOV is up to 99°X90° with the same accuracy.
High precision
Frame rate up to 120fps, resolution up to 1280x1080, sub-millimeter tracking accuracy and data stability.
Desktop location
The body length of the all-in-one machine is 14cm, and the integrated tracking and positioning function can be integrated into a portable body to do accurate positioning on the desktop, so as to realize the rapid implementation of the entire dynamic capture system.
Plug and play
The all-in-one machine, like the dynamic capture system composed of several other types of dynamic capture cameras, provides high precision, larger capture space, multi-object tracking and other functions.
Strong stability
Infrared optical tracking, no electrical, magnetic and sound interference interference, closed design, passive heat dissipation, while maintaining high performance away from dust, water and noise interference.
Easy to use
POE power supply supports wireless and wired data transmission, synchronization and other functions.
Supports two rigid body types
It supports active and passive rigid bodies and can adapt to different environments and usage scenarios, thus providing more accurate and stable positioning information.
Reliable performance
Our cameras have passed the ROHS, CE, FCC, VCCI certification, and the performance of the camera in high and low temperature environment, vibration environment and wet environment has been certified by professional testing institutions.
Learn about our detailed parameters.
- Resolution
- 1280*1080
- Frame Rate
- 120fps
- Focal Length
- 1mm
- FOV（HxV）
- 99°*90°
- Maximum Range
- 3m
- Tracking Accuracy
- ±0.5mm
- Tracking Range
- OptimalDistance：0.1m-1.5m
- Baseline
- 100mm
- Power Consumption
- 1w-5w
- Dimensions（WxHxD）
- 140mmx40mmx18mm
- Rigid Body Type
- Active Rigid Body,Passive Rigid Body
- Synchronization Method
- Wired and Wireless
- Weight
- 0.170KG
*Field of View (Typical)
All Cameras
| Parameters | Rigor | Smart | Nano | Nova | ||
| Resolution | 2048*2048 | 1280*1080 | 1280*1080 | Monochrome Fisheye Cameras *2: 1280×800/640*400 | Color Camera *1 4192×3104 | Depth Camera *1 640×480 |
| Frame Rate | 180fps | 120fps | 120fps | 60fps | 30fps | 30fps |
| Focal Length | 12/16mm | 1.9mm | 1mm | / | / | / |
| FOV（HxV） | 30°*47°/17°*36°* | 83°*72° | 99°*90° | 130°*74° | 68°*53° | 64°*50° |
| Maximum Range | 6m | 4.5m | 3m | / | / | / |
| Tracking Accuracy | ±0.2mm | ±0.3mm | ±0.5mm | / | / | / |
| Tracking Range | OptimalDistance：1m-3m | OptimalDistance：0.5m-2m | OptimalDistance：0.1m-1.5m | / | / | / |
| Baseline | 500mm | 220mm | 100mm | 80mm | / | / |
| Power Consumption | 12-22w | 3w-10w | 1w-5w | 2.8w | ||
| Dimensions （WxHxD） | 600×112×115(mm) | 300×56×43(mm) | 140×40×18(mm) | 128×28×30(mm) | ||
| Rigid Body Type | Active Rigid Body, Passive Rigid Body | Active Rigid Body, Passive Rigid Body | Active Rigid Body, Passive Rigid Body | Active Rigid Body, Passive Rigid Body | / | / |
| Synchronization Method | Wired and Wireless | Wired and Wireless | Wired and Wireless | / | / | / |
| Weight | 2.580KG | 0.903KG | 0.170KG | 0.093KG | ||
*Field of View (Typical)
